SIMATIC MP 277SIMATIC MP 277  6AV6643-0CD01-1AX1

  1. Siemens Human Machine Interface 10″ TFT DISPLAY
  2. TOUCH MULTI PANEL W. RETENTIVE
  3. MEMORY  6 MB USER MEMORY
  4. CONFIG: WINCC FLEXIBLE 2005 STANDARD SP1

DIMENSION:34.00X47.00X15.00 CM

Net weight:3.3kg

Price:USD 650.00

6AV6643-0CD01-1AX1 datasheet

Horizontal image resolution 640 Pixel
Vertical image resolution 480 Pixel
Design of display TFT
Screen diagonal 10.4 in
Color display Yes
Number of colors 65 536
Backlighting 50 000 h
Control elements  Touch screen
Control elements Touch screen
Design as touch screen Yes; analog, resistive
Connection type USB / USB / USB
Mounting position vertical

6av6643-0cd01-1ax1 Memory

Memory available for user data 6 Mbyte
128 Mbyte
Type of memory Flash / RAM
Interfaces  0ax0 0ax1 2ax0 0ba0 mp277 6av6642 6av6644
Number of RS 485 interfaces 1
Number of USB interfaces 2; Up to 1 GB
Multimedia card/SD card slot 1x Multimedia Card slot, up to 128 MB
Interfaces/bus type 1 x RS422, 1 x RS485, 1 x Ethernet (RJ45)
Industrial Ethernet 1 x Ethernet (RJ45)
Configuration software WinCC flexible Standard Version 2005 SP1 or higher
Message indicator Yes
Process value default (input) possible Yes
Recipe management Yes
Alarm system (incl. buffer and acknowledgment) Yes
Process value display (output) Yes

Functionality under WinCC (TIA Portal)

Help system Yes
Task planner Yes
Libraries Yes
Number of characters per info text 80
Number of process values per message 8
Acknowledgment groups Yes
Message indicator Yes
First/last value Yes
Number of alarm classes 32
Number of messages 4 000
Bit messages Yes
— Number of bit messages 4 000
Analog messages Yes
— Number of analog messages 200
System messages HMI Yes
System messages PLC Yes
System messages, other (SIMATIC S7, Sinumerik, Simotion, etc.) Yes
Lines 1
Entries per data record 1 000
Recipe memory 64 KB integrated Flash, expandable
Number of recipes 300
Data records per recipe 500
Limit values Yes
● Multiplexing Yes
Structures Yes
Number of variables per device 2 048
Number of variables per screen 200
Number of variables 1 000
Type Date & Time 2 048
Images 500
About details 6AV6643-0CD01-1AX1 datasheet,you can ask for us, we will send you immediately.
Also we supply New and Origin Siemens MP27710 6AV66430CD011AX1 Touch pad, the price is USD 50.00
If you want to buy  6AV6643-0CD01-1AX1 Touch pad, welcome to contact us!

the model 6AV6643-0CD01-1AX1 is blocked for delivery and no longer available as a new parts from Siemens manufacturer.

we still some in stock, and can supply you new parts with fast delivery time and best price.

6AV66430CD011AX1

6AV6643-0CD01-1AX1 replacement model,its successor, please contact Siemens Local branch.

if you need manual of 6AV6643-0CD01-1AX1, kindly click here.

Note that the model 6AV6643-0CD01-1AX1 already discontinued by Siemens since 2015, It was replaced by a MP 277/MP 377 panel family, but they have been discontinued themselves since 2015.

6AV6643-0CD01-1AX1
6av6643-0cd01-1ax1

More information about Siemens HMI:

  1.  basic
  2. comfort
  3. advance
  4. professional   the size is from 4 inch to 12 inch mainly.
