6AV2124-0MC01-0AX0
Price: USD 1800.00
Weight:3.44kg
Dimension:36.00×50.00×13.00 cm
Available in 15 units
Simens Human Machine Interface TP 1200 Comfort.SIMATIC Touch Screen,12″ WIDESCREEN-TFT-DISPLAY, 16 MIL. COLORS, MPI/PROFIBUS DP INTERFACE,WINDOWS CE 6.0, CONFIGURABLE FROM WINCC COMFORT V11.PROFINET INTERFACE, 12 MB USER MEMORY.
Data sheet 6AV2124-0MC01-0AX0
| Product type designation | TP1200 Comfort |
| Display | |
| Number of colors | 16 777 216 |
| Display height | 163.2 mm |
| Screen diagonal | 12.1 in |
| Design of display | TFT |
| Display width | 261.1 mm |
| Resolution (pixels) | |
| ● Horizontal image resolution | 1 280 Pixel |
| ● Vertical image resolution | 800 Pixel |
| Backlighting | 80 000 h |
| Installation type/mounting | |
| Mounting in landscape format possible | Yes |
| Mounting in portrait format possible | Yes |
| Mounting position | vertical |
| Permission Angle | 35° |
| Supply voltage | |
| permissible range, lower limit (DC) | 19.2 V |
| Type of supply voltage | DC |
| Rated value (DC) | 24 V |
| Interfaces | |
| Number of USB interfaces | 2; USB 2.0 |
| Number of RS 422 interfaces | 0; together with RS485 |
| Number of industrial Ethernet interfaces | 1; 2 ports (switch) |
| Number of RS 485 interfaces | 1; RS 422/485 combined |
| Number of RS 232 interfaces | 0 |
| ● USB Mini B | 1; 5-pole |
| Number of 20 mA interfaces (TTY) | 0 |
| Number of parallel interfaces | 0 |
| Number of other interfaces | 0 |
| Number of SD card slots | 2 |
| With software interfaces | No |
| Protocols (Ethernet) | |
| ● SNMP | Yes |
| ● DCP | Yes |
| ● LLDP | Yes |
| ● TCP/IP | Yes |
| ● DHCP | Yes |
| WEB characteristics | |
| HTML | Yes |
| CSS | Yes |
| XML | Yes |
| HTTP | Yes |
| HTTPS | Yes |
